Portable Pressure Calibrator เครื่องเปรียบเทียบความดันแบบพกพา
SPMK213B Low Pressure Comparator
Pressure Range: (-0.95-4) bar; (-14-60) psi
Adjustment Resolution: 0.1mbar; 10Pa
Connection: M20x1.5 Optional
Dimension: (250×135×140) mm
Net weight: 2.0Kg
Media: Air
Accessories: sealing component (10pcs), plug (2pcs)
SPMK213H Low Pressure Comparator
Pressure Range: (-0.95 to 25) bar; (-14 to 375) psi
Or: (-0.95 to 40) bar; (-14 to 600) psi
Adjustment Resolution: 1mbar; 0.1kPa
Connection: M20x1.5 Optional
Dimension: (280×170×140) mm
Net weight: 2.4Kg
Media: Air
Accessories: sealing component (10pcs), plug (2pcs)
SPMK213E High Pressure Comparator
Pressure Range: (-0.95 to 100) bar; (-14 to 1,500) psi
Adjustment Resolution: 10mbar; 1kPa
Connection: M20x1.5 Optional
Dimension: (500×325×135) mm
Net weight: 6.4Kg
Media: Air
Accessories: sealing component (10pcs), plug (2pcs)
SPMK214L High Pressure Comparator
Pressure Range: (0 to 700) bar; (0 to 10,000) psi
Adjustment Resolution: 0.2bar; 20kPa
Connection: M20x1.5 Optional
Dimension: (384×198×180) mm
Net weight: 4.7 Kg
Media: Oil
Accessories: sealing component (10pcs), plug (2pcs)
Desk-top Pressure Comparator เครื่องเปรียบเทียบความดันแบบตั้งโต๊ะ
SPMK2000E Pneumatic Pressure comparator
Pressure Range: (-0.95 to 60) bar; (-14 to 900) psi
Adjustment Resolution: 0.1mbar; 10Pa
Connection: M20x1.5 Optional
Dimension: (300×150×150) mm
Net weight: 10Kg
Media: Air
Accessories: sealing component (10pcs), plug (3pcs), cranking handle (1pcs)
SPMK990S Water Pressure Comparator
Pressure Rang e : (0 to 600) bar; (0 to 9,000) psi
Adjustment Resolution: 0.01bar; 1kPa
Connection: M20x1.5 Optional
Dimension: (410×310×120) mm
Net weight: 11Kg
Media: Pure Water
Accessories: sealing component (10pcs), plug (3pcs),
cranking handle (1pcs), drain-pipe (1pcs)
SPMK990Y Oil Pressure Comparator
Pressure Rang e : (0 to 600) bar; (0 to 9,000) psi
Adjustment Resolution: 0.01bar; 1kPa
Connection: M20x1.5 Optional
Dimension: (410×310×120) mm
Net weight: 11Kg
Media: Oil
Accessories: sealing component (10pcs), plug (3pcs),
cranking handle (1pcs), drain-pipe (1pcs)
SPMK213J Hydraulic Pressure Comparator
Pressure Rang e : (0 to 600) bar; (0 to 9,000) psi
Adjustment Resolution: 0.01bar; 1kPa
Connection: M20x1.5 Optional
Dimension: (410×310×120) mm
Net weight: 11Kg
Media: Pure Water
Accessories: sealing component (10pcs), plug (3pcs),
cranking handle (1pcs), drain-pipe (1pcs)
SPMK213K Ultrahigh Hydraulic Pressure Comparator
Pressure Range: (-0.85 to 2,500) bar; (-12.5 to 36,000) psi
Adjustment Resolution: 0.01bar; 1kPa
Connection: M20x1.5 Optional
Dimension: (565×375×305) mm
Net weight: 20.3Kg
Media: Oil
Accessories: sealing component (10pcs), plug (3pcs)
SPMK213K Ultrahigh Hydraulic Pressure Comparator
Pressure Range: (-0.85 to 2,500) bar; (-12.5 to 36,000) psi
Adjustment Resolution: 0.01bar; 1kPa
Connection: M20x1.5 Optional
Dimension: (565×375×305) mm
Net weight: 20.3Kg
Media: Oil
Accessories: sealing component (10pcs), plug (3pcs)
